PDG23F0040TFFJ Eaton Circuit Breaker

PDG23F0040TFFJ - Eaton Molded Case Circuit Breaker

Part Number:

PDG23F0040TFFJ

Manufacturer:
Eaton

Family:
Power Defense

Pole:
3

Amp
40

Volt:
600

Phase:
3

Category:

Molded Case / 3-Pole

Connection:
Feed-Thru

Type:
PDG

Functions:
LI - Long-Time and Instantaneous

Protection:
Thermal Magnetic

AIC Ratings:
25kA@480V

Frame Type:
Frame 2

Dimensions (HxWxD):
5.75x 4.12x 3.5

Weight:
4 lbs

PDG23F0040TFFJ - Eaton Molded Case Circuit Breaker
Eaton Power Defense Molded Case Circuit Breaker, Globally Rated, Frame 2, Three Pole, 40A, 25Ka/480V, T-M (Fxd-Fxd) Tu, Standard Line And Load (Pdg2X3T100)
Frame Size 2 covers a range of 15 A through 225 A with a complete offering of trip units, including PXR electronic trip units and fixed-fixed thermalmagnetic trip units.
Frame Size 2 can be used to meet a wide range of circuit protection and power distribution needs, including ground fault protection and current limiting options. PXR trip units in PD-2 provide all levels of protection, including energy metering with multiple communication schemes, breaker health indication, and zone selective interlocking with visual indication.
Frame Size 2 breakers are available in multiple ratings from 15 A through 225 A. They are configured with a trip unit from the factory. Accessories are modular in design to allow for field installation or factory configuration. PXR trip units are available with advanced features to provide customers unparalleled situational awareness of their electrical system.
